24A-D PARALLEL SHAFT PERMANENT MAGNET 24 VDC AND 130 VDC GEARMOTORS
24A Motor provides high starting torque, adjustable speed, and linear speed torque characteristics. Performance ratings at 130V are based on use with filtered controls (FF=1.0). Performance ratings at 24V are based on use with filtered controls (FF=1.0) or battery.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
| Model Number | Speed (rpm) | Motor HP | Rated Torque (lb-in) | Gear Ratio | Rated Voltage | Accessory Shaft | Price | |
|---|---|---|---|---|---|---|---|---|
| 0186 | 417 | 1/17 | 5.0 | 6 | 130V | NO | Call for Price | Call |
| 0187 | 208 | 1/17 | 12.0 | 6 | 130V | NO | Call for Price | Call |
| 0188 | 139 | 1/17 | 17.0 | 18 | 130V | NO | Call for Price | Call |
| 0189 | 83 | 1/17 | 29.0 | 30 | 130V | NO | Call for Price | Call |
| 0190 | 42 | 1/17 | 40.0 | 60 | 130V | NO | Call for Price | Call |
| 0191 | 417 | 1/29 | 3.0 | 6 | 130V | NO | Call for Price | Call |
| 0192 | 208 | 1/29 | 7.0 | 12 | 130V | NO | Call for Price | Call |
| 0193 | 139 | 1/29 | 11.0 | 18 | 130V | NO | Call for Price | Call |
| 0194 | 83 | 1/29 | 18.0 | 30 | 130V | NO | Call for Price | Call |
| 0195 | 142 | 1/29 | 36.0 | 60 | 130V | NO | Call for Price | Call |
| 0196 | 28 | 1/29 | 40.0 | 90 | 130V | NO | Call for Price | Call |
| 0197 | 14 | 1/29 | 40.0 | 180 | 130V | NO | Call for Price | Call |
| 0198 | 8 | 1/29 | 40.0 | 300 | 130V | NO | Call for Price | Call |
| 0199 | 6 | 1/29 | 40.0 | 450 | 130V | NO | Call for Price | Call |
| N4491 | 417 | 1/29 | 3.0 | 6 | 130V | YES | Call for Price | Call |
| N4492 | 208 | 1/29 | 7.0 | 12 | 130V | YES | Call for Price | Call |
| N4493 | 139 | 1/29 | 11.0 | 18 | 130V | YES | Call for Price | Call |
| N4494 | 83 | 1/29 | 18.0 | 30 | 130V | YES | Call for Price | Call |
| N4495 | 42 | 1/29 | 36.0 | 60 | 130V | YES | Call for Price | Call |
| N4496 | 28 | 1/29 | 40.0 | 90 | 130V | YES | Call for Price | Call |
| N4497 | 14 | 1/29 | 40.0 | 180 | 130V | YES | Call for Price | Call |
| N4498 | 8 | 1/29 | 40.0 | 300 | 130V | YES | Call for Price | Call |
| N4499 | 6 | 1/29 | 40.0 | 450 | 130V | YES | Call for Price | Call |
| 4690 | 42 | 1/17 | 40.0 | 60 | 24V | NO | Call for Price | Call |
| N4791 | 417 | 1/29 | 3.0 | 6 | 24V | NO | Call for Price | Call |
| N4792 | 208 | 1/29 | 5.0 | 12 | 24V | NO | Call for Price | Call |
| N4793 | 139 | 1/29 | 11.0 | 18 | 24V | NO | Call for Price | Call |
| N4794 | 83 | 1/29 | 18.0 | 30 | 24V | NO | Call for Price | Call |
| N4795 | 42 | 1/29 | 36.0 | 60 | 24V | NO | <Call for Price | Call |
| N4796 | 28 | 1/29 | 40.0 | 90 | 24V | NO | Call for Price | Call |
| N4797 | 14 | 1/29 | 40.0 | 180 | 24V | NO | Call for Price | Call |
| N4798 | 8 | 1/29 | 40.0 | 300 | 24V | NO | Call for Price | Call |
| N4799 | 6 | 1/29 | 40.0 | 450 | 24V | NO | Call for Price | Call |
| N4991 | 417 | 1/29 | 3.0 | 6 | 24V | YES | Call for Price | Call |
| N4992 | 208 | 1/29 | 5.0 | 12 | 24V | YES | Call for Price | Call |
| N4993 | 139 | 1/29 | 11.0 | 18 | 24V | YES | Call for Price | Call |
| N4994 | 83 | 1/29 | 18.0 | 30 | 24V | YES | Call for Price | Call |
| N4995 | 42 | 1/29 | 36.0 | 60 | 24V | YES | Call for Price | Call |
| N4996 | 28 | 1/29 | 40.0 | 90 | 24V | YES | Call for Price | Call |
| N4997 | 14 | 1/29 | 40.0 | 180 | 24V | YES | Call for Price | Call |
| N4998 | 8 | 1/29 | 40.0 | 300 | 24V | YES | Call for Price | Call |
| N4999 | 6 | 1/29 | 40.0 | 450 | 24V | YES | Call for Price | Call |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 5968 | "L" bracket kit for base, ceiling, and sidewall mounting | Call for Price | Call |
Matching Controls
We stock a full line of speed controls for our PMDC gearmotors and motors
