Bodine Electric Company
Pacesetter 30R-D Parallel Shaft 230 VAC 3 Phase Inverter Duty Gearmotors
Variable speed, 3-phase design for operation with a wide range of inverter (AC drive) products. Totally enclosed IP-20 rating. IP-44 with optional t-box kit installed. We offer most standard models with either 230 VAC, 60Hz, 3-phase, or 230/460 VAC, 60Hz, 3-phase winding options.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
Model numbers that begin with "N" may require additional lead time.
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| 2210 | 9 rpm | 40 lb-in | 1/25 | 180 | Call for Price | Call |
| N2212 | 19 rpm | 40 lb-in | 1/25 | 90 | Call for Price | Call |
| N2214 | 28 rpm | 40 lb-in | 1/25 | 60 | Call for Price | Call |
| 2216 | 142 rpm | 19 lb-in | 1/17 | 12 | Call for Price | Call |
| N2218 | 283 rpm | 9 lb-in | 1/17 | 6 | Call for Price | Call |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 5982 | Die cast standard terminal box kit | Call for Price | Call |
| 5968 | "L" Bracket kit for base, ceiling, and sidewall mounting | Call for Price | Call |
Matching Controls
We stock a full line of speed controls for our 230 VAC Pacesetter gearmotors and motors.
