Bodine Electric Company
33A-5L/H RIGHT ANGLE, HOLLOW BORE, PERMANENT MAGNET DC GEARMOTORS
33A Motor provides high starting torque, adjustable speed, and linear speed torque characteristics Performance ratings at 130V are based on use with filtered controls (FF=1.0). Performance ratings at 90V are based on use with filtered controls.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
| Model Number | Speed (rpm) @90/130 | Motor HP @90/130 | Rated Torque (lb-in) @90/130 | Gear Ratio | Accessory Shaft | Price | |
|---|---|---|---|---|---|---|---|
| N6734 | 345 / 500 | 1/8 / 1/4 | 17 / 22 | 5 | NO | Call for Price | Call | art
| 6735 | 173 / 250 | 1/8 / 1/4 | 31 / 42 | 10 | NO | Call for Price | Call |
| N6736 | 86 / 125 | 1/8 / 1/4 | 54 / 78 | 20 | NO | Call for Price | Call |
| N6737 | 58 / 83 | 1/8 / 1/4 | 75 / 100 | 30 | NO | Call for Price | Call |
| N6738 | 43 / 62 | 1/8 / 1/4 | 84 / 109 | 40 | NO | Call for Price | Call |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 0912 | Shaft Kit 5L/H 5/8-inch | Call for Price | Call |
| 0922 | Shaft Kit 5L/H 5/8-inch / double shaft | Call for Price | Call |
| 0951 | Cover Kit for 5L/H & GB/H Hollow Shaft Gearmotors | Call for Price | Call |
| 0956 | Flange Mount Kit for 5L/H & GB/H Hollow Shaft Gearmotors | Call for Price | Call |
| 0958 | Base Mount Kit for 5L/H Hollow Shaft Gearmotors | Call for Price | Call |
| 0977 | IP-44 kit for 33A motors | Call for Price | Call |
| 0984 | Die cast terminal box kit | Call for Price | Call |
| 0985 | Oversized die cast terminal box kit | Call for Price | Call |
| 1984 | Die cast metric terminal box kit with terminal block | Call for Price | Call |
Matching Controls
We stock a full line of speed controls for our PMDC gearmotors and motors
