Pacesetter 34R-FX Parallel Shaft 230 and 230/460 VAC 3 Phase Inverter Duty Gearmotors
Variable speed, 3-phase design for operation with a wide range of inverter (AC drive) products. Totally enclosed IP-20 rating. IP-44 with optional t-box kit installed. We offer most standard models with either 230 VAC, 60Hz, 3-phase, or 230/460 VAC, 60Hz, 3-phase winding options.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
Model numbers that begin with "N" may require additional lead time.
Single Voltage 230 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| N2256 | 5.7 rpm | 350 lb-in | 1/6 | 300 | Call for Price | Call |
| 2250 | 9.4 rpm | 350 lb-in | 1/6 | 180 | Call for Price | Call |
| 2251 | 19 rpm | 350 lb-in | 1/6 | 90 | Call for Price | Call |
| 2252 | 28 rpm | 321 lb-in | 1/6 | 60 | Call for Price | Call |
| 2253 | 57 rpm | 160 lb-in | 1/6 | 30 | Call for Price | Call |
| N2254 | 170 rpm | 53 lb-in | 1/6 | 10 | Call for Price | Call |
| N2255 | 340 rpm | 28 lb-in | 1/6 | 5 | Call for Price | Call |
Dual Voltage 230/460 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| 2856 | 5.7 rpm | 350 lb-in | 1/6 | 300 | Call for Price | Call |
| 2850 | 9.4 rpm | 350 lb-in | 1/6 | 180 | Call for Price | Call |
| 2851 | 19 rpm| 350 lb-in | 1/6 | 90 | Call for Price | Call |
| 2852 | 28 rpm | 321 lb-in | 1/6 | 60 | Call for Price | Call |
| 2853 | 57 rpm | 160 lb-in | 1/6 | 30 | Call for Price | Call |
| 2854 | 170 rpm | 53 lb-in | 1/6 | 10 | Call for Price | Call |
| 2855 | 340 rpm | 28 lb-in | 1/6 | 5 | Call for Price | Call |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 0984 | Die cast standard terminal box kit | Call for Price | Call |
| 0985 | Die cast oversized terminal box kit | Call for Price | Call |
| 1984 | Die cast metric standard terminal box kit | Call for Price | Call |
| 0969 | "L" Bracket kit for base, ceiling, and sidewall mounting | Call for Price | Call |
| 0995 | Adapter plate kit provides drop-in replacement of competitive gearmotors | Call for Price | Call |
Matching Controls
We stock a full line of speed controls for our 230 VAC Pacesetter gearmotors and motors.
