Pacesetter 42R-5L/H Right Angle Hollow Shaft 230 AND 230/460 VAC 3 Phase Inverter Duty Gearmotors
Variable speed, 3-phase design for operation with a wide range of inverter (AC drive) products. Totally enclosed IP-20 rating. IP-44 with optional t-box kit installed. We offer most standard models with either 230 VAC, 60Hz, 3-phase, or 230/460 VAC, 60Hz, 3-phase winding options.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
Model numbers that begin with "N" may require additional lead time.
Single Voltage 230 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| N2470 | 23 rpm | 121 lb-in | 3/8 | 75 | Call for Price | Call |
| N2471 | 43 rpm | 113 lb-in | 3/8 | 40 | Call for Price | Call |
| N2475 | 57 rpm | 109 lb-in | 3/8 | 30 | Call for Price | Call |
| 2472 | 85 rpm | 103 lb-in | 3/8 | 20 | Call for Price | Call |
| N2473 | 170 rpm | 101 lb-in | 3/8 | 10 | Call for Price | Call |
| N2474 | 340 rpm | 54 lb-in | 3/8 | 5 | Call for Price | Call |
Dual Voltage 230/460 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| N2670 | 23 rpm | 121 lb-in | 3/8 | 75 | Call for Price | Call |
| N2671 | 43 rpm | 113 lb-in | 3/8 | 40 | Call for Price | Call |
| N2673 | 170 rpm | 101 lb-in | 3/8 | 10 | Call for Price | Call |
| N2674 | 340 rpm | 54 lb-in | 3/8 | 5 | Call for Price | Call |
| N2675 | 57 rpm | 109 lb-in | 3/8 | 30 | Call for Price | Call |
| N2676 | 85 rpm | 103 lb-in | 3/8 | 20 | Call for Price | Call |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 0984 | Die cast standard terminal box kit | Call for Price | Call |
| 0985 | Die cast oversized terminal box kit | Call for Price | Call |
| 1984 | Die cast metric standard terminal box kit | Call for Price | Call |
Matching Controls
We stock a full line of speed controls for our 230 VAC Pacesetter gearmotors and motors.
