Bodine Electric Company
Pacesetter 42R-FX Parallel Shaft 230 and 230/460 VAC 3 Phase Gearmotors
Replacements for discontinued Baldor products:
- Model 2262 with the model 0984 terminal box can replace Baldor IDGMP2501
- Model 2263 with the model 0984 terminal box can replace Baldor IDGMP2500
- Model 2860 with the model 0984 terminal box can replace Baldor GMP3330
- Model 2861 with the model 0984 terminal box can replace Baldor GMP3332
- Model 2862 with the model 0984 terminal box can replace Baldor GMP3336
- Model 2863 with the model 0984 terminal box can replace Baldor GMP3338
Variable speed, 3-phase design for operation with a wide range of inverter (AC drive) products. Totally enclosed IP-20 rating. IP-44 with optional t-box kit installed. We offer most standard models with either 230 VAC, 60Hz, 3-phase, or 230/460 VAC, 60Hz, 3-phase winding options.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
Model numbers that begin with "N" may require additional lead time.
Single Voltage 230 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| 2260 | 57 rpm | 270 lb-in | 3/8 | 30 | Call for Price | Call |
| 2261 | 85 rpm | 240 lb-in | 3/8 | 20 | Call for Price | Call |
| 2262 | 170 rpm | 123 lb-in | 3/8 | 10 | Call for Price | Call |
| 2263 | 340 rpm | 58 lb-in | 3/8 | 5 | Call for Price | Call |
| N2264 | 113 rpm | 184 lb-in | 3/8 | 15 | Call for Price | Call |
Dual Voltage 230/460 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| 2860 | 57 rpm | 270 lb-in | 3/8 | 30 | Call for Price | Call |
| 2861 | 85 rpm | 240 lb-in | 3/8 | 20 | Call for Price | Call |
| 2862 | 170 rpm | 123 lb-in | 3/8 | 10 | Call for Price | Call |
| 2863 | 340 rpm | 58 lb-in | 3/8 | 5 | Call for Price | Call |
| 2864 | 113 rpm | 184 lb-in | 3/8 | 15 | Call for Price | Call |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 0984 | Die cast standard terminal box kit | Call for Price | Call |
| 0985 | Die cast oversized terminal box kit | Call for Price | Call |
| 1984 | Die cast metric standard terminal box kit | Call for Price | Call |
| 0969 | "L" Bracket kit for base, ceiling, and sidewall mounting | Call for Price | Call |
| 0995 | Adapter plate kit provides drop-in replacement of competitive gearmotors | Call for Price | Call |
Matching Controls
We stock a full line of speed controls for our 230 VAC Pacesetter gearmotors and motors.
