Bodine Electric Company
Pacesetter 42R-GB/H Right Angle Hollow Shaft 230 VAC 3 Phase Inverter Duty Gearmotors
Variable speed, 3-phase design for operation with a wide range of inverter (AC drive) products. Totally enclosed IP-20 rating. IP-44 with optional t-box kit installed. We offer most standard models with either 230 VAC, 60Hz, 3-phase, or 230/460 VAC, 60Hz, 3-phase winding options.
For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012
Model numbers that begin with "N" may require additional lead time.
Single Voltage 230 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| 2336 | 6 rpm | 380 lb-in | 3/8 | 280 | $967.41 | Add to Cart |
| N2337 | 14 rpm | 290 lb-in | 3/8 | 120 | $967.41 | Add to Cart |
| N2338 | 28 rpm | 230 lb-in | 3/8 | 60 | $967.41 | Add to Cart |
Dual Voltage 230/460 VAC
| P/N | Speed | Torque | HP | Gear Ratio | Price | |
|---|---|---|---|---|
| N2636 | 6 rpm | 380 lb-in | 3/8 | 280 | $1017.04 | Add to Cart |
| N2637 | 14 rpm | 290 lb-in | 3/8 | 120 | $1017.04 | Add to Cart |
| N2639 | 28 rpm | 230 lb-in | 3/8 | 60 | $1017.04 | Add to Cart |
Optional Accessories
| P/N | Description | Price | |
|---|---|---|---|
| 0984 | Die cast standard terminal box kit | $38.94 | Add to Cart |
| 0985 | Die cast oversized terminal box kit | $78.13 | Add to Cart |
| 1984 | Die cast metric standard terminal box kit | $56.02 | Add to Cart |
Matching Controls
We stock a full line of speed controls for our 230 VAC Pacesetter gearmotors and motors.
