Bodine Electric Company

48R-FX PARALLEL SHAFT 115/230 VAC CAPACITOR GEARMOTORS


Single speed, continuous duty rated.

Motors can operate on 115 or 230 VAC, 60Hz only.

Capacitor required for operation, order separately.

Totally enclosed, fan cooled IP-20 rating. IP-44 with optional t-box kit installed.

For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012

Single speed, continuous duty rated.

Motors can operate on 115 or 230 VAC, 60Hz only.

Capacitor required for operation, order separately.

Totally enclosed, fan cooled IP-20 rating. IP-44 with optional t-box kit installed.

For questions, non-listed part numbers, other available variations and accessories, please Email or call us today! (800)735-8012

Model numbers that begin with "N" may require additional lead time.


Model Number Speed (rpm) Torque Motor Output Power (hp) Gear Ratio Price
N5691 340 56 lb-in 1/3 5 $749.89 Add to Cart
N5692 170 109 lb-in 1/3 10 $749.89 Add to Cart
N5693 85 218 lb-in 1/3 20 $806.50 Add to Cart
N5694 57 270 lb-in 1/3 30 $806.50 Add to Cart
N5695 113 164 lb-in 1/3 15 $749.89 Add to Cart


Required Capacitor


P/N Description Price
49401057 Capacitor, 20 MFD / 350 VAC for 115 VAC operation $14.49 Add to Cart
49401107 Capacitor, 12.5 MFD / 370 VAC for 230 VAC operation $12.09 Add to Cart


Optional Accessories


P/N Description Price
0985 Die cast oversized terminal box kit $78.13 Add to Cart
0969 "L" bracket kit for base, ceiling, and sidewall mounting $45.05 Add to Cart
